NEI BOPP Thermal Lamination Film For Glossy And Matte Lamination Customization

NEI BOPP Thermal Lamination Film For Glossy And Matte Lamination Customization

  • NEI BOPP Thermal Lamination Film For Glossy And Matte Lamination Customization
NEI BOPP Thermal Lamination Film For Glossy And Matte Lamination Customization
Product Details:
Place of Origin: Guangdong, China
Brand Name: NEi
Certification: SGS Test Report / ISO9001 / ISO14001
Model Number: GLOSSY / MATTE
Payment & Shipping Terms:
Minimum Order Quantity: 1 Ton
Price: Negotiable
Packaging Details: 1. Packed in paper cartons firstly and then secured on wooden pallets. 2. All pallets are well packed with packing belts and well wrapped with stretch film.
Delivery Time: 15 -20 working days for one 20GP Container
Payment Terms: T/T, L/C, Western Union
Supply Ability: 1000 Tons per month
Contact Now
Detailed Product Description
Product Name:: BOPP Thermal Lamination Film Type:: Thermal Lamination Film
Material:: BOPP+EVA Processing Type:: Multiple Extrusion
Transparency:: Transparent Application:: Lamination For Photo Albums
Paper Core:: 3 Inch (1 Inch Available On Request) Thickness:: 25 Micron
Origin:: GUANGDONG,CHINA
Highlight:

Matte BOPP Thermal Lamination Film

,

NEI BOPP Thermal Lamination Film

,

Glossy BOPP Thermal Lamination Film



25 Micron Cell Phone Cases / Photo Lamination Film Fast Delivery NEI Brand





Glossy Specifications:



TYPE

THICKNESS (micron)

GLOSSY

TOTAL

BASE

EVA

17

12

5

18

12

6

20

12

8

22

12

10

23

15

8

25

15

10

27

15

12

30

15

15

42

28

14

WIDTH (mm)

200 ~ 2210

LENGTH (m)

100 ~ 8000

PAPER CORE

25.4mm(1 inch) / 76mm (3 inch)

BONDING

≤2

CORONA TREATED

Double side

SURFACE TENSION

38 Dyne/cm ≤ 42 Dyne/cm

LAMINATION TEMP.

90±10°C

ROLLER PRESSURE

10 ~ 20Mpa

LAMINATION SPEED

20 ~ 70M





Matte Specifications:



TYPE THICKNESS (micron)
MATTE TOTAL BASE EVA
17 12 5
18 12 6
20 12 8
22 12 10
23 15 8
25 15 10
27 15 12
30 15 15
43 28 15
WIDTH (mm) 200 ~ 2210
LENGTH (m) 100 ~ 8000
PAPER CORE 25.4mm(1 inch) / 76mm (3 inch)
BONDING ≤2
CORONA TREATED Double side
SURFACE TENSION 38 Dyne/cm ≤ 42 Dyne/cm
LAMINATION TEMP. 90±10°C
ROLLER PRESSURE 10 ~ 20Mpa
LAMINATION SPEED 20 ~ 70M





Description:



The surface of the thermolaminated film is coated with low-temperature molten resin extrusion, and the film can be laminated to the paper product by heat and pressure. A variety of surface treatments can add value to printed surfaces.



The glossy BOPP thermolaminated film provides a glossy colored finish. Its use can enhance the appearance and increase the service life of all laminated prints. Matte BOPP thermolaminate film provides a matte finish on print surfaces, preventing fingerprints and smudges. Matte films can be stored for a longer period of time than glossy thermolaminated films.



BOPP thermolaminated film with good performance and low price is ideal for all kinds of printed and unprinted paper and board, including book covers, cosmetic packaging, magazines, documents, shopping bags, diaries and more.





Applications:
Photo album, mobile phone case, USB cable packaging, headphone packaging, mobile accessories packaging, etc

NEI BOPP Thermal Lamination Film For Glossy And Matte Lamination Customization 0




Why chooses NEI BOPP thermal lamination film?



1. Environmentally friendly: It is non-toxic, odorless or benzene-free because it uses a non-solvent-based adhesive. It is environmentally friendly and harmless to human health as no toxic gases or volatile components are emitted during the laminating process. In addition, it is easier to recycle than water-based laminated film because the film and paper can be easily separated.


2. Safe operation: The use of non-solvent-based adhesives eliminates fire hazards caused by the use and storage of flammable solvents.


3. Excellent performance: Compared to wet laminating, thermal laminating film improves the color saturation and brightness of printed matter. It also has stronger powder absorption capacity and adhesion. In addition, it can effectively prevent foaming or separation from the stamping part during the lamination process. Due to its strong bonding ability and surface tension, it can be used in later processes, including point UV, hot stamping, die cutting, and indentation processes.


4. Easy to operate: Once the required temperature and pressure are reached, the lamination can be easily operated. No other special techniques are required.


5. High efficiency: Production costs and Labour costs are greatly reduced as there is no need for film waste, mixtures of adhesive solvents or UV heat lamps (drying systems). Therefore, it also saves production space.


6. Wide adaptability: Widely used in different types of laminating machines, including wet and dry laminating machines. If a wet laminator is used, only small adjustments to the machine are required.






Why chooses NEI?



1. NEI has professional experience in the film industry since 1995, so we have good quality control and after-sales service to support you.



2. 10 years of export experience, including South America, North America, the Middle East, Asia, Africa, Oceania and many other countries, so we have a good reputation in these fields.



3. Compared to other thermolaminated films, our EVA glue is 100% imported from Korea, ensuring the adhesion of our films.



4. Customized size and thickness according to customer requirements. Labels can also be customized.



5. Fast production and delivery.



6. Wide range of thermolaminated films and special films.






Special Instruction:



1. The recommended laminating roll temperature range for NE-BOPP thermolaminated films is 85 to 110°C and roll pressure is 10 to 20Mpa. However, the optimal conditions depend on the speed and dimensional stability of the laminator chosen.



2. It is recommended that the printed surface be sufficiently dry before laminating and that one surface be sufficiently cooled before laminating to another surface.
