BOPP Matte Film 43 Micron Thickness For Offset Printing

BOPP Matte Film 43 Micron Thickness For Offset Printing

BOPP Matte Film 43 Micron Thickness For Offset Printing
BOPP Matte Film 43 Micron Thickness For Offset Printing
BOPP Matte Film 43 Micron Thickness For Offset Printing
Product Details:
Place of Origin: Guangdong, China
Brand Name: NEi
Certification: SGS Test Report / ISO9001 / ISO14001
Model Number: MATTE
Payment & Shipping Terms:
Minimum Order Quantity: ONE PALLET
Price: Negotiable
Packaging Details: 1. Packed in paper cartons firstly and then secured on wooden pallets. 2. All pallets are well packed with packing belts and well wrapped with stretch film.
Delivery Time: 15 -20 working days for one 20GP Container
Payment Terms: T/T, L/C, Western Union
Supply Ability: 1000 Tons per month
Contact Now
Detailed Product Description
Product Name:: BOPP Thermal Lamination Film Type:: Thermal Lamination Film
Place Of Origin:: GUANGDONG,CHINA Material:: 28 Micron BOPP+ 15 Micron EVA
Processing Type:: Multiple Extrusion Transparency:: Transparent
Application:: Lamination For Offset Printing Paper Core:: 3 Inch (1 Inch Available On Request)
Finish:: Matte Thickness:: 43 Micron
Highlight:

Offset Printing BOPP Matte Film

,

43 Micron Thickness BOPP Matte Film

,

BOPP Matte Film



Multiple Extrusion Processing BOPP Matte Film 43 Micron Thickness For Offset Printing​





Glossy Specifications:



TYPE

THICKNESS (micron)

GLOSSY

TOTAL

BASE

EVA

17

12

5

18

12

6

20

12

8

22

12

10

23

15

8

25

15

10

27

15

12

30

15

15

42

28

14

WIDTH (mm)

200 ~ 2210

LENGTH (m)

100 ~ 8000

PAPER CORE

25.4mm(1 inch) / 76mm (3 inch)

BONDING

≤2

CORONA TREATED

Double side

SURFACE TENSION

38 Dyne/cm ≤ 42 Dyne/cm

LAMINATION TEMP.

90±10°C

ROLLER PRESSURE

10 ~ 20Mpa

LAMINATION SPEED

20 ~ 70M





Matte Specifications:



TYPE THICKNESS (micron)
MATTE TOTAL BASE EVA
17 12 5
18 12 6
20 12 8
22 12 10
23 15 8
25 15 10
27 15 12
30 15 15
43 28 15
WIDTH (mm) 200 ~ 2210
LENGTH (m) 100 ~ 8000
PAPER CORE 25.4mm(1 inch) / 76mm (3 inch)
BONDING ≤2
CORONA TREATED Double side
SURFACE TENSION 38 Dyne/cm ≤ 42 Dyne/cm
LAMINATION TEMP. 90±10°C
ROLLER PRESSURE 10 ~ 20Mpa
LAMINATION SPEED 20 ~ 70M





Description:



The hot pressed composite film has an extruded coating surface of low-temperature molten resin, which allows the film to be laminated onto paper products through heat and pressure. Various surface treatments can increase the value of printed surfaces.



Matte BOPP hot press film provides a matte finish on the surface of printed materials to prevent fingerprints and stains. Compared to glossy hot pressed films, matte films can be stored for a longer period of time.



43 micron BOPP matte hot press film (also known as hot press film or dry press film) is widely used for laminating various printed and non printed paper and paperboard, including book covers, cosmetic packaging, magazines, documents, shopping bags, diaries, etc. It can also be used for digital printing products with less silicone oil. This is because hot pressed films with thin EVA layers cannot be used for digital printing containing silicone oil. For digital printing using heavy silicone oil, it requires another special type of thermosensitive oil.



BOPP Matte Film 43 Micron Thickness For Offset Printing 0




The advantages of NEI BOPP thermal lamination film



1. Environmentally friendly: Due to the use of non solvent adhesives, it is non-toxic, odorless, or free of benzene. During the lamination process, no toxic gases or volatile substances are emitted, which is harmless to human health.
2. Safe operation
3. Excellent performance: improving the color saturation and brightness of printed materials; Has strong powder absorption ability and adhesion; Effectively prevent foaming or separation from printed materials during the lamination process.
4. Easy handling

5. High efficiency: Production costs, labor costs, and production space are all reduced.
6. Wide adaptability: widely applicable to different types of SMT machines, including wet and dry SMT machines. If using a wet laminating machine, only minor adjustments need to be made to the machine.






The Brand --- NEI



1. NEI has professional experience in film industry since 1995 so we have good quality control and after-sale services to support you.



2. With 10 years of export experience, we have a good reputation in many countries, including South America, North America, the Middle East, Asia, Africa, Oceania, and so on.



3. Compared with other thermal lamination film, our EVA glue is 100% imported from Korea and it ensures the adhesiveness of our film.



4. Customize size and thickness according to customer requests. Labels can be customized as well.



5. Rapid production and delivery.



6. A wide range of thermal lamination film and special films.






Special Instruction:



1. It is recommended to composite the NEI BOPP hot pressed film under roller temperature of 85-110 ℃ and roller pressure of 10-20 Mpa. However, the optimal conditions depend on the speed and dimensional stability of the selected laminating machine.



2. It is advised that the printed surface is well dried before lamination and cools sufficiently one surface before laminating to other surface.
