Place of Origin: | Guangdong, China |
Brand Name: | NEi |
Certification: | SGS Test Report / ISO9001 / ISO14001 |
Model Number: | ANTI SCRATCH |
Minimum Order Quantity: | 1000 SQM |
---|---|
Price: | Negotiable |
Packaging Details: | 1. Packed in paper cartons firstly and then secured on wooden pallets. 2. All pallets are well packed with packing belts and well wrapped with stretch film. |
Delivery Time: | 15 -20 working days for one 20GP Container |
Payment Terms: | T/T, L/C, Western Union |
Supply Ability: | 1000 Tons per month |
Product Name:: | Matt Anti-Scratch Thermal Lamination Film | Type:: | Thermal Lamination Film |
---|---|---|---|
Place Of Origin:: | Guangdong, China | Material:: | BOPP+EVA |
Processing Type:: | Multiple Extrusion | Transparency:: | Transparent |
Application:: | Lamination For Offset Printing | Paper Core:: | 1 Inch (3 Inch Available Upon Request) |
Surface Finish:: | Matte | Corona:: | Double |
Highlight: | Double Corona Anti Scratch Film,Anti Scratch Film Luxury Packaging |
Fashional Excellent Performance Anti Scratch Film , Digital Printing Film
Specifications:
TYPE | THICKNESS (micron) | ||
MATT | TOTAL | BASE | EVA |
35 | 20 | 15 | |
WIDTH (mm) | 100 ~ 1570 | ||
LENGTH (m) | 100m, 200m, 300m | ||
PAPER CORE | 25.4mm(1 inch) / 76mm (3 inch) | ||
BONDING | ≤2 | ||
CORONA TREATED | Double side | ||
SURFACE TENSION | 38 Dyne/cm ≤ 42 Dyne/cm | ||
LAMINATION TEMP. | 90±10°C | ||
ROLLER PRESSURE | 10 ~ 20Mpa | ||
LAMINATION SPEED | 20 ~ 50M |
Description:
The scratch resistant (wear resistant) hot press film has a top coating, a wear-resistant matte BOPP finish, and an additional matte appearance. The matte surface has a high dyne level for coatings, hot stamping, and UC ink. It avoids the slight scratches that typically occur on the surface of a matte laminated film.
At present, it has been widely used in the custom packaging industry, as well as various high-quality customized graphic solutions for high-end book covers, hardcover books, book covers, corporate brochures, product brands, and more. It is an ideal luxury packaging that is excellent for any product that requires high wear resistance to increase value in printing.
The 1-inch scratch resistant laminated film mini roll is designed for fast printing shops, with laminated printing and small laminating machines. Normal sizes include 300mm, 330mm, 360mm, 400mm, 420mm, etc.
Why chooses NEI matt anti-scratch thermal lamination film?
1. The best color deepening. No more color tonality change after lamination and dark colors intensified.
2. Environmentally friendly.
3. Safe operation: Non-solvent based adhesive is used so it will eliminate the fire hazard that is caused by the use and storage of flammable solvents.
4.Excellent performance: Compared with wet lamination, thermal lamination improves the color saturation and brightness of printed materials. Has strong powder absorption ability and adhesion. In addition, it can effectively prevent foaming or separation from the printed material during the lamination process. Due to its strong adhesive ability and surface tension, it can be used in subsequent processes, including spot UV, hot stamping, die-cutting, indentation, and other processes.
5. Easy handling: Once the required temperature and pressure is met, lamination can be easily operated. No other special technique is required.
6. High efficiency: Production cost and labor cost are reduced substantially as there is no film wastage, mixture of adhesive solvent, or no UV heating lamp (drying system) is required. Therefore, it saves production space as well.
7. Wide adaptability: It is widely adaptable to different types of lamination machines, including wet and dry laminator. Only small adjustments need to be made to the machine if wet laminator is used.
Why chooses NEI?
1. NEI has professional experience in film industry since 1995 so we have good quality control and after-sale services to support you.
2. 10 yeas of export experience to many countries, including South America, North America, Middle East, Asia, Africa, Oceania, etc. so we have good reputation in these areas.
3. Compared with other thermal lamination film, our EVA glue is 100% imported from Korea and it ensures the adhesiveness of our film.
4. Customize size and thickness according to customer requests. Labels can be customized as well.
5. Rapid production and delivery.
6. A wide range of thermal lamination film and special films.
Special Instruction:
1. NEI scratch resistant heat composite film is recommended to be laminated under roller temperature of 85-110 ℃ and roller pressure of 10-20 Mpa. However, the optimal conditions depend on the speed and dimensional stability of the selected laminating machine.
2. It is advised that the printed surface must be well dried before lamination and cools sufficiently one surface before laminating to other surface. Failure to comply with these suggestions will most likely cause pre-mature delamination.
3. This film has an extra matt finish, so we recommend handling it with cotton gloves or at least with washed and cleaned bare hands.
