| Place of Origin: | Guangdong, China |
| Brand Name: | NEi |
| Certification: | SGS Test Report / ISO9001 / ISO14001 |
| Model Number: | GLOSSY |
| Minimum Order Quantity: | one pallet |
|---|---|
| Price: | Negotiable |
| Packaging Details: | 1. Packed in paper cartons firstly and then secured on wooden pallets. 2. All pallets are well packed with packing belts and well wrapped with stretch film. |
| Delivery Time: | 15 -20 working days for one 20GP Container |
| Payment Terms: | T/T, L/C, Western Union |
| Supply Ability: | 1000 Tons per month |
| Product Name:: | Glossy BOPP Thermal Laminating Film | Type:: | Thermal Laminating Film |
|---|---|---|---|
| Place Of Origin:: | Guangdong, China | Material:: | BOPP+EVA |
| Transparency:: | Transparent | Application:: | Packaging Lamination |
| Paper Core:: | 1 Inch Or 3 Inch | Thickness:: | 17mic - 42 Mic |
| Length:: | 100m - 8000m | ||
| High Light: | Surface Finishes High Gloss Lamination Film,Double Side High Gloss Lamination Film |
||
Excellent Performance Gloss Lamination Film , Food Packaging Film Roll
Various Surface Finishes, High Gloss, Double Side Corona Treated, 25.4mm/76mm Paper Core
Glossy Specifications:
TYPE | THICKNESS (micron) | ||
GLOSSY | TOTAL | BASE | EVA |
17 | 12 | 5 | |
18 | 12 | 6 | |
20 | 12 | 8 | |
22 | 12 | 10 | |
23 | 15 | 8 | |
25 | 15 | 10 | |
27 | 15 | 12 | |
30 | 15 | 15 | |
42 | 28 | 14 | |
WIDTH (mm) | 200 ~ 2210 | ||
LENGTH (m) | 100 ~ 8000 | ||
PAPER CORE | 25.4mm(1 inch) / 76mm (3 inch) | ||
BONDING | ≤2 | ||
CORONA TREATED | Double side | ||
SURFACE TENSION | 38 Dyne/cm ≤ 42 Dyne/cm | ||
LAMINATION TEMP. | 90±10°C | ||
ROLLER PRESSURE | 10 ~ 20Mpa | ||
LAMINATION SPEED | 20 ~ 70M | ||
Description:
The hot-pressed composite film has an extruded coating surface of molten resin at low temperature, so that the film is laminated to the paper product by heat and pressure. A variety of surface treatments can add value to the printed surface. The glossy BOPP hot press film provides a shiny colored finish. Its use can enhance the appearance and increase the service life of all laminated prints.
With its good performance characteristics and low price, BOPP hot press film is ideal for all kinds of printed and non-printed paper and cardboard, including book covers, cosmetic packaging, magazines, documents, shopping bags, diaries, maps, etc.
The Advantages NEI BOPP thermal lamination film VS cold laminating film
NEI Quality Control
Special Instruction:
1. NEI smooth BOPP hot pressing film is recommended to adopt the composite process of roll temperature 85 ~ 110℃ and roll pressure 10 ~ 20 Mpa. However, the optimal conditions depend on the speed and dimensional stability of the laminator chosen.
2. It is recommended that printed surfaces dry sufficiently before laminating and that one surface be sufficiently cooled before laminating onto other surfaces.
