Place of Origin: | Guangdong, China |
Brand Name: | NEi |
Certification: | SGS Test Report / ISO9001 / ISO14001 |
Model Number: | MATTE |
Minimum Order Quantity: | 500kgs / Trail Order Negotiable |
---|---|
Price: | Negotiable |
Packaging Details: | 1. Packed in paper cartons firstly and then secured on wooden pallets. 2. All pallets are well packed with packing belts and well wrapped with stretch film. |
Delivery Time: | 15 -20 working days for one 20GP Container |
Payment Terms: | T/T, L/C, Western Union |
Supply Ability: | 1000 Tons per month |
Product Name:: | BOPP Thermal Lamination Film | Type:: | Hot Lamination Film |
---|---|---|---|
Material:: | BOPP+EVA | Processing Type:: | Multiple Extrusion |
Transparency:: | Transparent | Paper Core:: | 3 Inch (1 Inch Available On Request) |
High Light: | BOPP Matte Lamination Film,Offset Printing Matte Lamination Film,Matte Lamination Film Transparent |
Matte Offset Printing BOPP Lamination Film Multiple Extrusion Processing Environmentally Friendly
Matte Specifications:
TYPE | THICKNESS (micron) | ||
MATTE | TOTAL THICKNESS | BASE | EVA |
17 | 12 | 5 | |
18 | 12 | 6 | |
20 | 12 | 8 | |
22 | 12 | 10 | |
23 | 15 | 8 | |
25 | 15 | 10 | |
27 | 15 | 12 | |
30 | 15 | 15 | |
43 | 28 | 15 | |
WIDTH (mm) | 100 ~ 2200 | ||
LENGTH (m) | 100 ~ 4500 | ||
PAPER CORE | 25.4mm(1 inch) / 76mm (3 inch) | ||
BONDING | ≤2 | ||
CORONA TREATED | Double side | ||
SURFACE TENSION | 38 Dyne/cm ≤ 42 Dyne/cm | ||
LAMINATION TEMP. | 90±10°C | ||
ROLLER PRESSURE | 10 ~ 20Mpa | ||
LAMINATION SPEED | 20 ~ 70M |
Description:
The hot laminated film has an extruded coating surface with low-temperature molten resin, which can be laminated onto the paper product by heating and pressure. Various surface treatments can add value to the printed surface. The matte BOPP hot laminating film provides a matte effect on the surface of the printing machine to prevent fingerprints and stains. Compared with the glossy hot lamination film, the matt film can be stored for a longer time.
A combination of good performance characteristics and low price point make BOPP thermal laminating films ideal for all kinds of printed & unprinted paper and paper boards, including book covers, cosmetics packaging, magazines, documents, shopping bags, Diaries etc.
Application:
Paper cartons, cosmetics packaging, candy boxes, sweet boxes, books, magazines, toy packaging, cell-phone packaging, suitable for all types of paper packaging.
Why chooses NEI BOPP thermal lamination film?
1. Eco-friendly: Non-toxic, odorless or benzene-free due to the use of non-solvent-based adhesives. It is environmentally friendly and harmless to human health because no toxic gases or volatile substances are emitted during the lamination process. In addition, it is easier to recycle than water-based laminated film because the membrane and paper can be easily separated.
2. Safe operation: Non-solvent based adhesive is used so it will eliminate the fire hazard that is caused by the use and storage of flammable solvents.
3. Excellent performance: Compared to wet pressed film, hot-pressed film can improve the color saturation and brightness of the print. It has strong powder absorption ability and adhesion. In addition, it effectively prevents foaming or separation from the laminate during the lamination process. Because it has strong adhesion ability and surface tension, it can be used in post-production processes, including spot UV, hot stamping, die-cutting, indentation process.
4. Easy handling: Once the required temperature and pressure is met, lamination can be easily operated. No other special technique is required.
5. High efficiency: Production cost and labor cost are reduced substantially as there is no film wastage, mixture of adhesive solvent, or no UV heating lamp (drying system) is required. Therefore, it saves production space as well.
6. Wide adaptability: widely used in different types of laminators, including wet and dry laminators. If a wet laminator is used, only minor adjustments to the machine are required.
Why chooses NEI?
1. NEI has professional experience in film industry since 1995 so we have good quality control and after-sale services to support you.
2. 10 yeas of export experience to many countries, including South America, North America, Middle East, Asia, Africa, Oceania, etc. so we have good reputation in these areas.
3. Compared with other thermal lamination film, our EVA glue is 100% imported from Korea and it ensures the adhesiveness of our film.
4. Customize size and thickness according to customer requests. Labels can be customized as well.
Special Instruction:
1. NEI glossy BOPP thermal laminate film with a roll temperature range of 85 to 110°C and a roll press of 10 to 20 Mpa is recommended. However, the optimal conditions depend on the speed and dimensional stability of the selected laminator
2. It is advised that the printed surface is well dried before lamination and cools sufficiently one surface before laminating to other surface.
