Home ProductsGloss Lamination Film

High Glossy Flexible Packaging Films Biaxially Oriented Polypropylene Moisture Proof 18 Mic Thickness

High Glossy Flexible Packaging Films Biaxially Oriented Polypropylene Moisture Proof 18 Mic Thickness

High Glossy Flexible Packaging Films Biaxially Oriented Polypropylene Moisture Proof 18 Mic Thickness
High Glossy Flexible Packaging Films Biaxially Oriented Polypropylene Moisture Proof 18 Mic Thickness
High Glossy Flexible Packaging Films Biaxially Oriented Polypropylene Moisture Proof 18 Mic Thickness
Product Details:
Place of Origin: Guangdong, China
Brand Name: NEi
Certification: SGS Test Report / ISO9001 / ISO14001
Model Number: GLOSSY
Payment & Shipping Terms:
Minimum Order Quantity: 1 Ton / Trail Order Negotiable
Price: Negotiable
Packaging Details: 1. Packed in paper cartons firstly and then secured on wooden pallets. 2. All pallets are well packed with packing belts and well wrapped with stretch film.
Delivery Time: 15 -20 working days for one 20GP Container
Payment Terms: T/T, L/C, Western Union
Supply Ability: 1000 Tons per month
Contact Now
Detailed Product Description
Type:: Thermal Laminating Film Place Of Origin:: Guangdong, China
Feature:: Moisture Proof Hardness:: Soft
Application:: Lamination For Printing Paper Core:: 3 Inch Or 1 Inch
Label:: Neutral Or Customized Thickness:: 18 Micron
Base Film:: Biaxially Oriented Polypropylene Film Glue:: EVA From Korean
High Light:

High Glossy Flexible Packaging Films

,

Polypropylene Flexible Packaging Films

,

Moisture Proof Flexible Packaging Films



High Glossy Flexible Packaging Films Moisture Proof 18 Mic Thickness

High Glossy Flexible Packaging Films Biaxially Oriented Polypropylene Film Moisture Proof 18 Mic Thickness



Glossy and Matte Specifications:



TYPE

THICKNESS (micron)

GLOSSY / MATTE

TOTAL

BASE FILM

EVA GLUE

17

12

5

18

12

6

20

12

8

22

12

10

23

15

8

25

15

10

27

15

12

30

15

15

42

28

14

WIDTH (mm)

200 ~ 2200

LENGTH (m)

100 ~ 4000

PAPER CORE

25.4mm(1 inch) / 76mm (3 inch)

BONDING

≤2

CORONA TREATED

Double side

SURFACE TENSION

38 Dyne/cm ≤ 42 Dyne/cm

LAMINATION TEMP.

90±10°C

ROLLER PRESSURE

10 ~ 20Mpa

LAMINATION SPEED

20 ~ 100M





Description Of Thermal Lamination Film:



Thermal Lamination Films have extrusion-coated surface with low temperature melting resin, which enables the lamination of film to paper products by heat and pressure. Various surface finishes available add value to the printed surface. Glossy BOPP thermal lamination film offers a shiny colorful finish. Its use can enhance the look and increase all laminated presswork’s useful lifetime.



Good performance characteristics and low price make BOPP thermal composite film an ideal choice for all kinds of printed and unprinted paper and paperboard, including book covers, cosmetics packaging, magazines, documents, shopping bags, diaries, etc.



Hot film is also called hot film, hot film, hot film and pre film. 18 micron bopp thermal composite membrane is widely used in Vietnam, Thailand, Indonesia, Egypt, Brazil, Mexico, Chile, Colombia and other countries because of its low cost per square meter.





Normal Applications:

  1. Documents
  2. Price tags, labels
  3. Shopping bags
  4. Children books & school books
  5. Paper cartons
  6. Different kinds of boxes, e.g., cosmetic box, medicine box, wine box, beer box, candy box.



NEI BOPP thermal lamination film is widely used in the market because:



1. Environmentally friendly: non-toxic, odorless, or non-benzene because non-solvent based adhesive is used.


2. Safe operation: Non-solvent based adhesive is used so it will eliminate the fire hazard that is caused by the use and storage of flammable solvents.


3. Excellent performance: enhances the color saturation and brightness of presswork; have stronger ability of absorbing powder and adhesive force; effective to prevent being blistered or separated from presswork in lamination process.


4. Easy handling: Once the required temperature and pressure is met, lamination can be easily operated. No other special technique is required.


5. High efficiency: Production cost and labor cost are reduced substantially as there is no film wastage, mixture of adhesive solvent, or no UV heating lamp (drying system) is required. Therefore, it saves production space as well.


6. Wide adaptability: It is widely adaptable to different types of lamination machines, including wet and dry laminator. Only small adjustments need to be made to the machine if wet laminator is used.








Special Instruction Of BOPP Thermal Lamination Film:



1. NEI glossy BOPP thermal lamination film is suggested to be laminated with the roller temperature range of 85 to 110°C and roller pressure of 10 to 20 Mpa. However, the optimum conditions are depending on the selected laminator’s speed and dimensional stability.



2. It is advised that the printed surface is well dried before lamination and cools sufficiently one surface before laminating to other surface.
