Place of Origin: | Guangdong, China |
Brand Name: | NEi |
Certification: | SGS Test Report / ISO9001 / ISO14001 |
Model Number: | Gloss & Matt |
Minimum Order Quantity: | 1 Ton / Trail Order Negotiable |
---|---|
Price: | Negotiable |
Packaging Details: | 1. Packed in paper cartons firstly and then secured on wooden pallets. 2. All pallets are well packed with packing belts and well wrapped with stretch film. |
Delivery Time: | 15 -20 working days for one 20GP Container |
Payment Terms: | L/C, T/T |
Supply Ability: | 1000 Tons per month |
Product Name:: | True Color BOPP Thermal Lamination Film Matt Film | Type:: | Thermal Lamination |
---|---|---|---|
Brand Name:: | NEI | Place Of Origin:: | Guangdong, China |
Material:: | BOPP+EVA | Processing Type:: | Multiple Extrusion |
Transparency:: | Transparent | Application:: | Lamination For Offset Printing |
Legnth:: | 2000,3000,4000m | ||
Highlight: | Clear BOPP Thermal Lamination Film,3000m Legnth BOPP Thermal Lamination Film,Matte BOPP Thermal Lamination Film |
Clear BOPP Thermal Lamination Film Focus On Clarity And Adhesion 17mic - 43mic
Specifications of BOPP Thermal Lamination Film:
TYPE | THICKNESS (micron) | ||
Matt | TOTAL | BASE | EVA |
17 | 12 | 5 | |
18 | 12 | 6 | |
20 | 12 | 8 | |
22 | 12 | 10 | |
23 | 15 | 8 | |
25 | 15 | 10 | |
27 | 15 | 12 | |
28 | 15 | 13 | |
30 | 15 | 15 | |
43 | 18 | 25 | |
WIDTH (mm) | 200 ~ 2210 | ||
LENGTH (m) | 100 ~ 8000 | ||
PAPER CORE | 25.4mm(1 inch) / 76mm (3 inch) | ||
BONDING | ≤2 | ||
CORONA TREATED | Double side | ||
SURFACE TENSION | 38 Dyne/cm ≤ 42 Dyne/cm | ||
LAMINATION TEMP. | 90±10°C | ||
ROLLER PRESSURE | 10 ~ 20Mpa | ||
LAMINATION SPEED | 20 ~ 70M |
Description of BOPP Thermal Lamination Film:
Thermal lamination is an extruded film coated with low-temperature melting resin, which can be coated into paper products by heating and pressure. Various surface treatments can increase the value of printed surfaces. Matte white BOPP hot laminating film provides a matt treatment on the surface of printed materials. Compared with the gloss thermal lamination, the storage time of the matt film is longer.
Combined with good performance characteristics and low price, the white BOPP thermal composite film is ideal for all kinds of printed and unprinted paper and paperboard, including book covers, cosmetics packaging, magazines, documents, shopping bags, diaries, etc.
Why chooses True Color BOPP Thermal Lamination Film ?
NEI is your best choice!!
Special Instruction of BOPP Thermal Lamination Film:
The composite roll temperature range of NEI BOPP thermal composite film glossy film is 85~110 ℃, and the rolling range is 10~20 Mpa. However, the optimum conditions depend on the speed and dimensional stability of the selected laminator.
It is recommended that the printing surface be fully dried before laminating and fully cooled before laminating to another surface.
Applications of BOPP Thermal Lamination Film:
Packaging of BOPP Thermal Lamination Film:
