| Place of Origin: | Guangdong, China |
| Brand Name: | NEi |
| Certification: | SGS Test Report / ISO9001 / ISO14001 |
| Model Number: | ANGLE PASTING |
| Minimum Order Quantity: | 1000 SQM |
|---|---|
| Price: | Negotiable |
| Packaging Details: | 1. Packed in paper cartons firstly and then secured on wooden pallets. 2. All pallets are well packed with packing belts and well wrapped with stretch film. |
| Delivery Time: | 15 -20 working days for one 20GP Container |
| Payment Terms: | T/T, L/C, Western Union |
| Supply Ability: | 1000 Tons per month |
| Product Name:: | Angle Pasting Thermal Lamination Film | Type:: | Thermal Lamination Film |
|---|---|---|---|
| Place Of Origin:: | GUANGDONG,CHINA | Material:: | PET+EVA |
| Processing Type:: | Multiple Extrusion | Transparency:: | Transparent |
| Application:: | Lamination For Offset Printing | Paper Core:: | 3 Inch (1 Inch Available On Request) |
| Surface Finish:: | Glossy | ||
| High Light: | High Temp Resistant Corner Tape,Corner Tape 75 Micron |
||
3 Inch Corner Tape Thermal Lamination Film 22 Micron 65 Micron 75 Micron
High-Temp Resistant Corner Tape 65 Micron 75 Micron
Specifications:
| TYPE | THICKNESS (micron) | ||
| GLOSSY | TOTAL | BASE | EVA |
| 22 | 12 | 10 | |
| 65 | 38 | 27 | |
| 75 | 50 | 25 | |
| WIDTH (mm) | 14mm, 19mm, 25mm (Width can be customized) | ||
| LENGTH (m) | 300 ~ 4000 | ||
| PAPER CORE | 25.4mm(1 inch) / 76mm (3 inch) | ||
| BONDING | ≤2 | ||
| CORONA TREATED | Double side | ||
| SURFACE TENSION | 38 Dyne/cm ≤ 42 Dyne/cm | ||
| LAMINATION TEMP. | 90 ± 10°C | ||
| ROLLER PRESSURE | 10 ~ 20Mpa | ||
| LAMINATION SPEED | 20 ~ 70M | ||
Description:
PET corner paste hot press film is specifically designed for box corner paste. Widely used in paper box corner making machines, replacing corner paper tape. Compared to paper tape, this angle adhesive film is waterproof and has stronger adhesion. Therefore, the service life of the cardboard box is longer.
Why chooses NEI PET angle pasting thermal lamination film corner tape?
1. High-temperature resistant, fast bonding, and less waste.
2. Waterproof and stronger adhesive.
3. Environmentally friendly: Due to the use of non solvent adhesives, it is non-toxic, odorless, or free of benzene. During the lamination process, no toxic gases or volatile substances are emitted, which is harmless to human health. In addition, it is easier to recover than water-based laminated membranes because the membrane and paper can be easily separated.
4. Operational safety: The use of non solvent adhesives eliminates fire hazards caused by the use and storage of flammable solvents.
5.Excellent performance: Compared with wet lamination, thermal lamination improves the color saturation and brightness of printed materials. Has strong powder absorption ability and adhesion. In addition, it can effectively prevent foaming or separation from the printed material during the lamination process. Due to its strong adhesive ability and surface tension, it can be used in subsequent processes, including spot UV, hot stamping, die-cutting, indentation, and other processes.
6. Easy handling: Once the required temperature and pressure is met, lamination can be easily operated. No other special technique is required.
7. High efficiency: No waste of film, no mixing of adhesive solvents, no need for UV heating lamps (drying systems), greatly reducing production and labor costs. Therefore, it also saves production space.
8. Wide adaptability: widely applicable to different types of SMT machines, including wet and dry SMT machines. If using a wet laminating machine, only minor adjustments need to be made to the machine.
Why chooses NEI?
1. NEI has professional experience in film industry since 1995 so we have good quality control and after-sale services to support you.
2. With 10 years of export experience, we have a good reputation in many countries, including South America, North America, the Middle East, Asia, Africa, Oceania, and so on.
3. Compared to other hot pressed films, our EVA adhesive is 100% imported from South Korea, ensuring the adhesion of the film.
4. Customize size and thickness according to customer requests. Labels can be customized as well.
5. Rapid production and delivery.
6.Widespread hot pressed film and special thin film.
Special Instruction:
1. It is recommended to composite the NEI BOPP hot pressed film under roller temperature of 85-110 ℃ and roller pressure of 10-20 Mpa. However, the optimal conditions depend on the speed and dimensional stability of the selected laminating machine.
2. It is always used together with the corner machine, so the width of the corner strap can be customized.
