Customized Hot Laminator Clear Book Covering Film Multiple Extrusion Processing

Customized Hot Laminator Clear Book Covering Film Multiple Extrusion Processing

    • Customized Hot Laminator Clear Book Covering Film Multiple Extrusion Processing
    • Customized Hot Laminator Clear Book Covering Film Multiple Extrusion Processing
  • Customized Hot Laminator Clear Book Covering Film Multiple Extrusion Processing

    Product Details:

    Place of Origin: Guangdong, China
    Brand Name: NEi
    Certification: SGS Test Report / ISO9001 / ISO14001
    Model Number: GLOSSY / MATTE

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Ton / Trail Order Negotiable
    Price: Negotiable
    Packaging Details: 1. Packed in paper cartons firstly and then secured on wooden pallets. 2. All pallets are well packed with packing belts and well wrapped with stretch film.
    Delivery Time: 15 -20 working days for one 20GP Container
    Payment Terms: T/T, L/C, Western Union
    Supply Ability: 1000 Tons per month
    Contact Now
    Detailed Product Description
    Product Name:: BOPP Thermal Lamination Film Type:: Hot Lamination Film
    Place Of Origin:: Guangdong, China Material:: BOPP+EVA
    Processing Type:: Multiple Extrusion Transparency:: Transparent
    Application:: Lamination For Catalogs Paper Core:: 3 Inch (1 Inch Available On Request)
    Thickness:: 27 Micron



    Customized Hot Laminator Clear Book Covering Film Multiple Extrusion Processing



    Glossy Specifications:



    TYPE

    THICKNESS (micron)

    GLOSSY

    TOTAL

    BASE

    EVA

    17

    12

    5

    18

    12

    6

    20

    12

    8

    22

    12

    10

    23

    15

    8

    25

    15

    10

    27

    15

    12

    30

    15

    15

    42

    28

    14

    WIDTH (mm)

    200 ~ 2210

    LENGTH (m)

    100 ~ 8000

    PAPER CORE

    25.4mm(1 inch) / 76mm (3 inch)

    BONDING

    ≤2

    CORONA TREATED

    Double side

    SURFACE TENSION

    38 Dyne/cm ≤ 42 Dyne/cm

    LAMINATION TEMP.

    90±10°C

    ROLLER PRESSURE

    10 ~ 20Mpa

    LAMINATION SPEED

    20 ~ 70M





    Matte Specifications:



    TYPE THICKNESS (micron)
    MATTE TOTAL BASE EVA
    17 12 5
    18 12 6
    20 12 8
    22 12 10
    23 15 8
    25 15 10
    27 15 12
    30 15 15
    43 28 15
    WIDTH (mm) 200 ~ 2210
    LENGTH (m) 100 ~ 8000
    PAPER CORE 25.4mm(1 inch) / 76mm (3 inch)
    BONDING ≤2
    CORONA TREATED Double side
    SURFACE TENSION 38 Dyne/cm ≤ 42 Dyne/cm
    LAMINATION TEMP. 90±10°C
    ROLLER PRESSURE 10 ~ 20Mpa
    LAMINATION SPEED 20 ~ 70M





    Description:



    Thermal Lamination Films have extrusion-coated surface with low temperature melting resin, which enables the lamination of film to paper products by heat and pressure. Various surface finishes available add value to the printed surface.



    Glossy BOPP thermal lamination film offers a shiny colorful finish. Its use can enhance the look and increase all laminated presswork’s useful lifetime. Matt BOPP thermal lamination film provides a matt-finish on the surface of presswork, protecting from fingerprints and smudges. Compared with gloss thermal lamination film, matt film can be preserved for longer period of time.



    A combination of good performance characteristics and low price point make BOPP thermal laminating films ideal for all kinds of printed & unprinted paper and paper boards, including book covers, cosmetics packaging, magazines, documents, shopping bags, Diaries etc.



    Customized Hot Laminator Clear Book Covering Film Multiple Extrusion Processing






    Why chooses NEI BOPP thermal laminating film for book lamination?



    1. Environmentally friendly: It is non-toxic, odorless, or non-benzene because non-solvent based adhesive is used. It is environmentally friendly and non-hazardous to human health since no toxic gases or volatile content is emitted during lamination process. In addition, it is easier to recycle than water-based lamination film because film and paper can be easily separated.


    2. Safe operation: Non-solvent based adhesive is used so it will eliminate the fire hazard that is caused by the use and storage of flammable solvents.


    3. Excellent performance: Compared with wet lamination, thermal lamination film enhances the color saturation and brightness of presswork. It also has stronger ability of absorbing powder and adhesive force. Furthermore, it is effective to prevent being blistered or separated from presswork in lamination process.


    4. Easy handling: Once the required temperature and pressure is met, lamination can be easily operated. No other special technique is required.


    5. High efficiency: Production cost and labor cost are reduced substantially as there is no film wastage, mixture of adhesive solvent, or no UV heating lamp (drying system) is required. Therefore, it saves production space as well.






    NEI Team



    1. NEI has professional experience in film industry since 1995 so we have good quality control and after-sale services to support you.



    2. 10 yeas of export experience to many countries, including South America, North America, Middle East, Asia, Africa, Oceania, etc.



    3. Compared with other thermal lamination film, our EVA glue is 100% imported from Korea and it ensures the adhesiveness of our film.



    4. Customize size, thickness and labels can be customized.



    5. Rapid production and delivery.



    6. A wide range of thermal lamination film and special films.






    Notes For Instruction:



    1. NEI BOPP thermal lamination film is suggested to be laminated with the roller temperature range of 85 to 110°C and roller pressure of 10 to 20 Mpa. However, the optimum conditions are depending on the selected laminator’s speed and dimensional stability.



    2. It is advised that the printed surface is well dried before lamination and cools sufficiently one surface before laminating to other surface.
