17 Micron High Brightness Presswork Hot Lamination Roll For Mobile , Eva Lamination Film

17 Micron High Brightness Presswork Hot Lamination Roll For Mobile , Eva Lamination Film

17 Micron High Brightness Presswork Hot Lamination Roll For Mobile , Eva Lamination Film
17 Micron High Brightness Presswork Hot Lamination Roll For Mobile , Eva Lamination Film
17 Micron High Brightness Presswork Hot Lamination Roll For Mobile , Eva Lamination Film
Product Details:
Place of Origin: Guangdong, China
Brand Name: NEi
Certification: SGS Test Report / ISO9001 / ISO14001
Model Number: GLOSSY
Payment & Shipping Terms:
Minimum Order Quantity: 1000 SQM
Price: Negotiable
Packaging Details: 1. Packed in paper cartons firstly and then secured on wooden pallets. 2. All pallets are well packed with packing belts and well wrapped with stretch film.
Delivery Time: 15 -20 working days for one 20GP Container
Payment Terms: T/T, L/C, Western Union
Supply Ability: 1000 Tons per month
Contact Now
Detailed Product Description
Product Name:: Glossy BOPP Thermal Lamination Film Type:: Pro-coating Film
Place Of Origin:: Guangdong, China Material:: 12 Micron BOPP+ 5 Micron EVA
Feature:: Moisture Proof Hardness:: Soft
Application:: Lamination For Presswork Paper Core:: 3 Inch (1 Inch Available On Request)
Surface Finish: Glossy Thickness:: 17 Mic



High Brightness Presswork Hot Lamination Roll For Mobile , Eva Lamination Film





Glossy Specifications:



TYPE

THICKNESS (micron)

GLOSSY

TOTAL

BASE

EVA

17

12

5

18

12

6

20

12

8

22

12

10

23

15

8

25

15

10

27

15

12

30

15

15

42

28

14

WIDTH (mm)

200 ~ 2210

LENGTH (m)

100 ~ 8000

PAPER CORE

25.4mm(1 inch) / 76mm (3 inch)

BONDING

≤2

CORONA TREATED

Double side

SURFACE TENSION

38 Dyne/cm ≤ 42 Dyne/cm

LAMINATION TEMP.

90±10°C

ROLLER PRESSURE

10 ~ 20Mpa

LAMINATION SPEED

20 ~ 70M





Description:



The hot pressed composite film has an extruded coating surface of low-temperature molten resin, which allows the film to be laminated onto paper products through heat and pressure. Various surface treatments can increase the value of printed surfaces. The glossy BOPP hot press film provides a shiny colored finish. Its use can improve the appearance and increase the lifespan of all laminated printed materials.



A combination of good performance characteristics and low price point make BOPP thermal laminating films ideal for all kinds of printed & unprinted paper and paper boards, including book covers, cosmetics packaging, magazines, documents, shopping bags, Diaries etc.



Hot press film, also known as HOT LAMINATION FILM,and hydrophilic coating film. seventeen μ M bopp hot pressed film is widely used in countries such as Vietnam, Thailand, Indonesia, Egypt, Brazil, Mexico, Chile, Colombia, etc.





Normal Application:

  1. Documents
  2. Price tags, labels
  3. Shopping bags
  4. Children books
  5. School books






NEI BOPP thermal lamination film is widely used in the market because:



1. Environmentally friendly: non-toxic, odorless, or non-benzene because non-solvent based adhesive is used.


2. Safe operation: Non-solvent based adhesive is used so it will eliminate the fire hazard that is caused by the use and storage of flammable solvents.


3. Excellent performance: Compared with wet lamination, thermal lamination improves the color saturation and brightness of printed materials. Has strong powder absorption ability and adhesion. In addition, it can effectively prevent foaming or separation from the printed material during the lamination process.


4. Easy handling: Once the required temperature and pressure is met, lamination can be easily operated. No other special technique is required.


5. High efficiency: No waste of film, no mixing of adhesive solvents, no need for UV heating lamps (drying systems), greatly reducing production and labor costs. Therefore, it also saves production space.


6. Wide adaptability: It is widely adaptable to different types of lamination machines, including wet and dry laminator. Only small adjustments need to be made to the machine if wet laminator is used.






Who is NEI???



1. NEI has professional experience in film industry since 1995 so we have good quality control and after-sale services to support you.



2. 10 yeas of export experience to many countries, including South America, North America, Middle East, Asia, Africa, Oceania, etc. so we have good reputation in these areas.



3. Compared with other thermal lamination film, our EVA glue is 100% imported from Korea and it ensures the adhesiveness of our film.



4. Customize size and thickness according to customer requests. Labels can be customized as well.



5. Rapid production and delivery.



6. A wide range of thermal lamination film and special films.






Special Instruction:



1. NEI glossy BOPP thermal lamination film is suggested to be laminated with the roller temperature range of 85 to 110°C and roller pressure of 10 to 20 Mpa. However, the optimum conditions are depending on the selected laminator’s speed and dimensional stability.



2. It is advised that the printed surface is well dried before lamination and cools sufficiently one surface before laminating to other surface.
